Equipment include : uncoiler、punching press、strip coiling 、wire pay-off stand 、forming machine 、razor wire coiling machine 、the blade feeding part
Main technical parameter:
This machine undertake by three wrap wire machine and one main machin that can cut nine barb belt make up.
It reflects perfectly:
1. High efficiency:can produce the steel belt 80kgs per hour.
2. It is low to loss, the raw materials loss of the old model is 40%, and JC-9 type drops to 15%.
External dimension:
1. The wrap wire machine(long *width *high): 2 X 1.3mX 0.7mX 1.1m
2. The main machine (steel belt presses judging machine) (Long *width *high): 1.1mX 0.85mX2.0m
3. Accept wire machine(Long *width *high): 1.4mX 0.75mX 1.0m
4,Control method : electric cabinet
5,Blade thickness: 0.35mm-0.55mm
6,Wire diameter : 2.4mm-2.6mm
7,Output :80-150kg/h
8,Power :10kw
9,Weight :3500kg
